letsencrypt cheatsheet for AlmaLinux
1 letsencrypt for Apache and nginx
2 Apache
This section is sparse. Just adding some file locations.
2.1 Apache config files for letsencrypt
- /etc/httpd/conf.d/*.conf
- /etc/httpd/conf/httpd.conf
- /etc/httpd/conf/ssl.conf #+ENDSRC
2.2 files
/var/log/httpd
/var/lib/httpd
# contains the httpd state/etc/httpd/conf/httpd.conf
# the main config file!/etc/httpd/conf/magic
# contains the mime types supported/etc/httpd/conf.d/php.conf
/etc/httpd/conf.d/welcome.conf
/etc/httpd/conf.d/userdir.conf
/etc/httpd/conf.d/autoindex.conf
see man 5 httpd.conf which states that the main config file for apache is:
/etc/httpd/conf/httpd.conf
2.3 other possible config files:
2.3.1 specifiying documentroot in httpd.conf
I would check
/etc/apache3/httpd.conf
/etc/apache2/apache2.conf
/etc/httpd/httpd.conf
/etc/htpd/conf/httpd.conf
on my centos system it was in:
-/etc/httpd
specifically
-/etc/httpd/
3 Securing apache.
Most of this was gleaned from this youtube link.
3.1 Keep apache up-to-date
dnf upgrade httpd
3.2 Securing apache and wordpress users
Each of these daemons should be run by a least privileged user
, and NOT run
by root.
- Make the user have
nologin
shell. Here are a few lines of/etc/passwd
where you can see that these users have least privileges.zintis:x:1000:1000::/home/zintis:/bin/bash apache:x:48:48:Apache:/usr/share/httpd:/sbin/nologin mysql:x:27:27:MySQL Server:/var/lib/mysql:/sbin/nologin nginx:x:992:989:Nginx web server:/var/lib/nginx:/sbin/nologin
To change a user to use /sbin/nologin
use the command:
chsh /sbin/nologin apache
OR
usermod -s /sbin/nologin apache
- Ensure all the files in
/var/www
are owned byapache
with groupapache
:cd /var/www ; chown apache:apache *
- change the home directory of each user. So for apache -> /var/www/html
sudo vipw
and change the home directory to/var/www/html
- or,
usermod -m -d /var/www/html apache
-d
is an abbreviation for--home
and changes the user's home directory
Typically you would run these commands as a common sequence:
mkdir /home/new_home_directory
chown username:username /home/new_home_directory
chmod 700 /home/new_home_directory
usermod --home /home/new_home_directory username
3.3 Securing httpd.conf lines
You can change global directory security settings, or override these global
settings for a particular directory with the AllowOverride yes
Otherwise
just the global settings will take effect.
Starting from DocumentRoot "/var/www/html"
<Directory> Require ip 77.68.0.0/16 127.0.0.1/32 Require ip 2001:db8::a00:20ff:fea7:ccea Require ip 2001:db8:1:1::a Require ip 2001:db8:2:1::/64 Require ip 2001:db8:3::/48 </Directory>
4 Linode SSL certificates
From this linode community posting:
"While Linode is not a Certificate Authority and doesn't offer SSLs for purchasing, you can use any 3rd party SSL certificate on a Linode server.
You can install an SSL on many different Linux configurations. Here are a few guides for the most popular distributions and web servers:
CentOS:SSL Certificates with Apache on CentOS 7
Ubuntu: SSL Certificates with Apache on Debian & Ubuntu
Each web server (Apache, Nginx) will need to be configured to work with your third-party certificates, depending on your websites and requirements.
5 Let's Encrpt and Certbot
One of the easiest methods for obtaining and installing an SSL certificate is
through Let's Encrypt
. The Electronic Frontier Foundation
(EFF) has developed
Certbot, a free and automated tool for creating Let's Encrypt SSLs and
configuring them for different web server software. /Certbot runs on your
Linode and can be downloaded on Certbot's website.
6 Log of letsencrpyt.org and certbot on apache
Here is the final output of my certbot --apache
command:
certbot --apache Saving debug log to /var/log/letsencrypt/letsencrypt.log Plugins selected: Authenticator apache, Installer apache Which names would you like to activate HTTPS for? - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1: www.acme.org 2: zinux.acme.org - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Select the appropriate numbers separated by commas and/or spaces, or leave input blank to select all options shown (Enter 'c' to cancel): 1 Cert not yet due for renewal You have an existing certificate that has exactly the same domains or certificate name you requested and isn't close to expiry. (ref: /etc/letsencrypt/renewal/www.acme.org.conf) What would you like to do? - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1: Attempt to reinstall this existing certificate 2: Renew & replace the certificate (may be subject to CA rate limits) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Select the appropriate number [1-2] then [enter] (press 'c' to cancel): 1 Keeping the existing certificate Created an SSL vhost at /etc/httpd/conf.d/wordpress-le-ssl.conf Deploying Certificate to VirtualHost /etc/httpd/conf.d/wordpress-le-ssl.conf Redirecting vhost in /etc/httpd/conf.d/wordpress.conf to ssl vhost in /etc/httpd/conf.d/wordpress-le-ssl.conf - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Congratulations! You have successfully enabled https://www.acme.org - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Subscribe to the EFF mailing list (email: admin@acme.org). IMPORTANT NOTES: - If you like Certbot, please consider supporting our work by: Donating to ISRG / Let's Encrypt: https://letsencrypt.org/donate Donating to EFF: https://eff.org/donate-le root@zinux ~[1037]$
6.1 root "history" of letsencrpt CA install
Run April 23, 2021 Key to this process are the snap install commands, and the certbot –apache command. See certbot.eff.org/docs
dnf install snapd iptables -L iptables -S iptables -A INPUT -p tcp -m tcp --dport 80 -j LOG --log-prefix " Remote web " --log-level 6 iptables -A INPUT -p tcp -m tcp --dport 80 -j ACCEPT iptables -A INPUT -p tcp -m tcp --dport 443 -j LOG --log-prefix " Remote https " --log-level 6 iptables -A INPUT -p tcp -m tcp --dport 443 -j ACCEPT systemctl enable --now snapd.socket systemctl start snapd snap install core snap refresh core dnf list --installed | grep certbot dnf remove certbot lst /var/lib/snapd/ ln -s /var/lib/snapd/snap /snap snap install --classic certbot ln -s /snap/bin/certbot /usr/bin/certbot dnf install mod_ssl which ssl_module ssr httpd apachectl -M | grep ssl certbot --apache
Then you can check if your auto-renew is set up correctly. I found that
crontab -l
had zero entries, so I looked further with:
systemctl list-timers
systemctl list-timers NEXT LEFT LAST PASSED UNIT ACTIVATES Fri 2021-04-23 11:40:00 EDT 6min left Fri 2021-04-23 11:30:04 EDT 3min 37s ago sysstat-collect.timer sysstat-collect.service Fri 2021-04-23 12:22:15 EDT 48min left Fri 2021-04-23 11:22:14 EDT 11min ago dnf-makecache.timer dnf-makecache.service Fri 2021-04-23 16:23:55 EDT 4h 50min left Thu 2021-04-22 16:23:55 EDT 19h ago systemd-tmpfiles-clean.timer systemd-tmpfiles-clean.s> Fri 2021-04-23 19:01:00 EDT 7h left n/a n/a snap.certbot.renew.timer snap.certbot.renew.servi> Sat 2021-04-24 00:00:00 EDT 12h left Fri 2021-04-23 00:00:00 EDT 11h ago unbound-anchor.timer unbound-anchor.service Sat 2021-04-24 00:07:00 EDT 12h left Fri 2021-04-23 00:07:00 EDT 11h ago sysstat-summary.timer sysstat-summary.service Sat 2021-04-24 06:18:24 EDT 18h left Fri 2021-04-23 06:17:02 EDT 5h 16min ago dnf-automatic.timer dnf-automatic.service 7 timers listed. Pass --all to see loaded but inactive timers, too. root@zinux ~[1003]$
Of note is the snap.certbot.renew.timer line. So looks good.
6.2 Monitoring certbot installation
The obvious one is looking at what certificates you have instaslled:
certbot certificates
certbot certificates Saving debug log to /var/log/letsencrypt/letsencrypt.log - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Found the following certs: Certificate Name: www.acme.org Serial Number: 381beada275ecacc9cb450278104dcacb28 Key Type: RSA Domains: www.acme.org Expiry Date: 2021-07-22 14:05:28+00:00 (VALID: 89 days) Certificate Path: /etc/letsencrypt/live/www.acme.org/fullchain.pem Private Key Path: /etc/letsencrypt/live/www.acme.org/privkey.pem - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - root@zinux /etc/letsencrypt[1073]$
Looks good.
6.3 SSL Labs to check installation
You can usewww.ssllabs.com to check your letsencrypt installation:
This failed for me. I believe it is because my certbot –apache gave me the
option of creating a cert for www.acme.org
which I took. However, my
apache2 setup seems to only have acme.org
(no www).
- fix by recreating a cert for acme.org?
- fix by getting apache to use www.acme.org?
- The domain name is an alias for a web site whose main name is different, but the alias was not included in the certificate by mistake
I am not sure which way to go…. hmmmmm
I will try 1) and include an alias 3) so, I will delete my certbot
certificate by running certbot --apache
again, and replace it.
I am getting this:
root@zinux /var/www/html[1085]$ certbot --apache Saving debug log to /var/log/letsencrypt/letsencrypt.log Plugins selected: Authenticator apache, Installer apache Which names would you like to activate HTTPS for? - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1: www.acme.org 2: zinux.acme.org - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Select the appropriate numbers separated by commas and/or spaces, or leave input blank to select all options shown (Enter 'c' to cancel): c Please specify --domains, or --installer that will help in domain names autodiscovery, or --cert-name for an existing certificate name. root@zinux /var/www/html[1086]$ certbot --apache --domains acme.org Saving debug log to /var/log/letsencrypt/letsencrypt.log Plugins selected: Authenticator apache, Installer apache Requesting a certificate for acme.org Performing the following challenges: http-01 challenge for acme.org Waiting for verification... Cleaning up challenges We were unable to find a vhost with a ServerName or Address of acme.org. Which virtual host would you like to choose? - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1: wordpress-le-ssl.conf | Multiple Names | HTTPS | Enabled 2: wordpress.conf | Multiple Names | | Enabled 3: ssl.conf | | HTTPS | Enabled - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Select the appropriate number [1-3] then [enter] (press 'c' to cancel): c No vhost exists with servername or alias of acme.org. No vhost was selected. Please specify ServerName or ServerAlias in the Apache config. No vhost selected IMPORTANT NOTES: - Unable to install the certificate - Congratulations! Your certificate and chain have been saved at: /etc/letsencrypt/live/acme.org/fullchain.pem Your key file has been saved at: /etc/letsencrypt/live/acme.org/privkey.pem Your certificate will expire on 2021-07-22. To obtain a new or tweaked version of this certificate in the future, simply run certbot again with the "certonly" option. To non-interactively renew *all* of your certificates, run "certbot renew" root@zinux /var/www/html[1087]$
So, I then changed the apache httpd.conf file to specify my server correctly from www.acme.org to just acme.org. the restarted httpd, but still I got this:
root@zinux /etc/httpd/conf[1097]$ certbot --apache --domains acme.org Saving debug log to /var/log/letsencrypt/letsencrypt.log Plugins selected: Authenticator apache, Installer apache Cert not yet due for renewal You have an existing certificate that has exactly the same domains or certificate name you requested and isn't close to expiry. (ref: /etc/letsencrypt/renewal/acme.org.conf) What would you like to do? - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1: Attempt to reinstall this existing certificate 2: Renew & replace the certificate (may be subject to CA rate limits) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Select the appropriate number [1-2] then [enter] (press 'c' to cancel): 2 Renewing an existing certificate for acme.org We were unable to find a vhost with a ServerName or Address of acme.org. Which virtual host would you like to choose? - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1: wordpress-le-ssl.conf | Multiple Names | HTTPS | Enabled 2: wordpress.conf | Multiple Names | | Enabled 3: ssl.conf | | HTTPS | Enabled - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Select the appropriate number [1-3] then [enter] (press 'c' to cancel): c No vhost exists with servername or alias of acme.org. No vhost was selected. Please specify ServerName or ServerAlias in the Apache config. No vhost selected IMPORTANT NOTES: - Unable to install the certificate - Congratulations! Your certificate and chain have been saved at: /etc/letsencrypt/live/acme.org/fullchain.pem Your key file has been saved at: /etc/letsencrypt/live/acme.org/privkey.pem Your certificate will expire on 2021-07-22. To obtain a new or tweaked version of this certificate in the future, simply run certbot again with the "certonly" option. To non-interactively renew *all* of your certificates, run "certbot renew" root@zinux /etc/httpd/conf[1098]$
But???? I checked to browse to acme.org and now got a valid secure certificate?????
Lets check ssllab.com…
7 !%\(@#T^\) getting in trouble now:
trying to get my wordpress config, my apache config, my hostnamectl, my dns all to match acme.org, but now letsencrypt.org giving me this grieve:
certbot --apache --domain acme.org Saving debug log to /var/log/letsencrypt/letsencrypt.log Plugins selected: Authenticator apache, Installer apache Cert not yet due for renewal You have an existing certificate that has exactly the same domains or certificate name you requested and isn't close to expiry. (ref: /etc/letsencrypt/renewal/acme.org.conf) What would you like to do? - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1: Attempt to reinstall this existing certificate 2: Renew & replace the certificate (may be subject to CA rate limits) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Select the appropriate number [1-2] then [enter] (press 'c' to cancel): 2 Renewing an existing certificate for acme.org An unexpected error occurred: There were too many requests of a given type :: Error creating new order :: too many certificates already issued for exact set of domains: acme.org: see https://letsencrypt.org/docs/rate-limits/ Please see the logfiles in /var/log/letsencrypt for more details. root@zintis /etc/httpd/conf.d[1019]$
7.1 Discussion on deleting certs
I found this discussion on community.letsencrypt.org that points out the tricky nature of getting your certs straightened out.
Seems that the best solution is let them expire (after 90 days).
Another, slightly later discussion has some better info: here
The user got his error:
usage: certbot [SUBCOMMAND] [options] [-d DOMAIN] [-d DOMAIN] ... Certbot can obtain and install HTTPS/TLS/SSL certificates. By default, it will attempt to use a webserver both for obtaining and installing the certificate. certbot: error: unrecognized arguments:
8 Commercial Certificate from GoDaddy
I caved and bought the EV certificate from GoDaddy that expires in 2 years, (April 2023). That has yet to be applied to acme.org, awaiting for confirmation.
9 Removing certificates from Apache config
From a 6 year old post:
The reason why the restart you mention fails is probably because you're commenting out the certificate in a general config file and leave it in some other file, probably in a vhost config. You could check for that with this: grep -E '(domain[12]\.certificate|localhost\.crt) /etc/httpd/sites-enabled/*', which will search for the strings: domain1.certificate, domain2.certificate and localhost.crt in all files in /etc/httpd/sites-enabled/ directory. If it finds either of these strings it will print out the relevant lines prepended with the filename containing them. You can then proceed to comment out those lines. You may have to change the certificate file path in order to provide another certificate or comment out the whole HTTPS section if you only want plain HTTP. Try to restart (or test configuration) after you're done. If you get through a restart successfully, then the server has stopped using the certificates.
Another key bit of info on certs: "This file (localhost.crt) is generated with the script /etc/pki/tls/certs/make-dummy-cert on Red Hat, CentOS, and derivatives. You should not need it after you configure your web server to use the DigiCert certificate, but I wanted to add this to the conversation. – Aaron Copley Dec 2 '14 at 21:40 "
And more: You can regenerate the default self-signed certificate using OpenSSL:
openssl req -x509 -nodes -days 365 -newkey rsa:2048 -keyout /etc/pki/tls/private/localhost.key -out /etc/ssl/certs/localhost.crt
- You can search the Apache config files and replace the self-signed cert with the new certificate.
This command will tell you which Apache config files reference the localhost.crt file:
grep -i -r localhost.crt etc/httpd An example output of the above command might be this:
/etc/httpd/conf.d/ssl.conf:SSLCertificateFile /etc/pki/tls/certs/localhost.crt That tells us to look in /etc/httpd/conf.d/ssl.conf and update the SSLCertificateFile, SSLCertificateKeyFile, and SSLCertificateChainFile to their new DigiCert certificate files.
Please feel free to call DigiCert support at 1-801-701-9600 if you have any problems or questions.
From this lin:
The files /etc/pki/tls/certs/localhost.crt and /etc/pki/tls/private/localhost.key are created by the postinstall script of the mod_ssl package. You can find the CentOS 7 spec file here: https://git.centos.org/rpms/httpd/blob/c7/f/SPECS/httpd.spec (check the other branches for different CentOS versions). Here is the script from CentOS 7: %define sslcert %{_sysconfdir}/pki/tls/certs/localhost.crt %define sslkey %{_sysconfdir}/pki/tls/private/localhost.key %post -n mod_ssl umask 077 if [ -f %{sslkey} -o -f %{sslcert} ]; then exit 0 fi %{_bindir}/openssl genrsa -rand /proc/apm:/proc/cpuinfo:/proc/dma:/proc/filesystems:/proc/interrupts:/proc/ioports:/proc/pci:/proc/rtc:/proc/uptime 2048 > %{sslkey} 2> /dev/null FQDN=`hostname` if [ "x${FQDN}" = "x" -o ${#FQDN} -gt 59 ]; then FQDN=localhost.localdomain fi cat << EOF | %{_bindir}/openssl req -new -key %{sslkey} \ -x509 -sha256 -days 365 -set_serial $RANDOM -extensions v3_req \ -out %{sslcert} 2>/dev/null -- SomeState SomeCity SomeOrganization SomeOrganizationalUnit ${FQDN} root@${FQDN} EOF So if you delete both localhost.key and localhost.crt, and do yum reinstall mod_ssl, then the postinstall script will recreate them for you. (I'm posting this answer because searching how to recreate /etc/pki/tls/certs/localhost.crt leads me here, but as others stated, if you got a cert signed by a CA, you don't need the localhost.crt and localhost.key files any more.)
More:
just had this same problem. There was no default localhost certificate for CentOS 8 so I ran this and it regenerated all the default certs. /usr/libexec/httpd-ssl-gencerts Hope it helps someone else.
10 Move to nginx
I ran the godaddy certificates for 1 year. In the meantime, I also switched to nginx. So now I have no inconsistencies on the web server name. It is www.acme.org (not acme.org)
10.1 Run certbot
root@zintis /etc/pki/tls[1011]$ certbot --nginx Saving debug log to /var/log/letsencrypt/letsencrypt.log Enter email address (used for urgent renewal and security notices) (Enter 'c' to cancel): admin@acme.org - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Please read the Terms of Service at https://letsencrypt.org/documents/LE-SA-v1.3-September-21-2022.pdf. You must agree in order to register with the ACME server. Do you agree? - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - (Y)es/(N)o: Y - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Would you be willing, once your first certificate is successfully issued, to share your email address with the Electronic Frontier Foundation, a founding partner of the Let's Encrypt project and the non-profit organization that develops Certbot? We'd like to send you email about our work encrypting the web, EFF news, campaigns, and ways to support digital freedom. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - (Y)es/(N)o: Y Account registered. Which names would you like to activate HTTPS for? We recommend selecting either all domains, or all domains in a VirtualHost/server block. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1: www.acme.org - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Select the appropriate numbers separated by commas and/or spaces, or leave input blank to select all options shown (Enter 'c' to cancel): 1 Requesting a certificate for www.acme.org Successfully received certificate. Certificate is saved at: /etc/letsencrypt/live/www.acme.org/fullchain.pem Key is saved at: /etc/letsencrypt/live/www.acme.org/privkey.pem This certificate expires on 2023-07-27. These files will be updated when the certificate renews. Certbot has set up a scheduled task to automatically renew this certificate in the background. Deploying certificate Successfully deployed certificate for www.acme.org to /etc/nginx/conf.d/www.acme.org.conf Congratulations! You have successfully enabled HTTPS on https://www.acme.org - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - If you like Certbot, please consider supporting our work by: * Donating to ISRG / Let's Encrypt: https://letsencrypt.org/donate * Donating to EFF: https://eff.org/donate-le - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - root@zintis /etc/pki/tls[1012]$
